Getting Juniper Network Connect VPN Client Running on Mac OS X 10.6+

Affiliates of InCHIP can use VPN software to connect securely to the campus network from off-campus. This software, called Junos Pulse, must be downloaded to your computer, installed and configured. To connect using the full VPN client, download it below, install and configure it as directed. Affiliates of InCHIP can use VPN software to connect securely to the campus network from off-campus. This software, called Junos Pulse, must be downloaded to your computer, installed and configured. To connect using the full VPN client, download it below, install and configure it as directed. Express VPN Best for privacy. Number of IP addresses: 30,000 Number of servers: 3,000+ 3 months free with 1-year plan.

There are a number of problems getting the Juniper Network Connect VPN client running on the Mac. The permissions on directories are not correct after install, there are issues with the 64 bit kernel, problems if VMWare or Parallels is installed, etc. These instructions are the result of research I did to get Network Connect 6.2.0 running on OS X 10.6.8 (Snow Leopard). If you have Network Connect installed already you should uninstall it completely.

Juniper Network Connect For Mac

Uninstall Juniper Network Connect Mac

To Remove Network Connect
You may not have some of the files listed to run or remove and you can just skip those steps. You should review these steps carefully particularly if you have other Juniper products installed. They remove directories that may include installations of other Juniper products. These instructions should be run from your home directory.

  1. sudo /usr/local/juniper/nc/install/uninstall_nc.sh
  2. sudo rm -R /Applications/Network Connect.app
  3. sudo rm -R /usr/local/juniper
  4. sudo rm -R /Library/Frameworks/net.juniper.*
  5. sudo rm -R /Library/Internet Plug-ins/net.juniper.*
  6. sudo rm -R /Library/Widgets/Network Connect.wdgt
  7. sudo rm /private/var/db/receipts/net.juniper.*
  8. rm -R Library/Application Support/Juniper Networks
  9. rm -R Library/Caches/net.juniper.NetworkConnect
  10. rm Library/Preferences/net.juniper.NetworkConnect.plist
  11. rm -R Library/Logs/Juniper Networks
Juniper Network Connect For Mac

To Install Network Connect

  1. Download NetworkConnect.dmg. I was unable to get the applet installer from the VPN login to work correctly. You can download the dmg file directly from your vpn site. Add the path “/dana-cached/nc/NetworkConnect.dmg” to your VPN URL. If your VPN login is at https://vpn.mycompany.com/… then you would download from https://vpn.mycompany.com/dana-cached/nc/NetworkConnect.dmg. You may have to login to the VPN site to access the download.
  2. Open NetworkConnect.dmg and run the installer. If you get an error saying there is already a version installed do the uninstall steps above.
  3. sudo chmod 755 /usr/local/juniper/nc/[version number]
  4. sudo mkdir ‘/Applications/Network Connect.app/Contents/Frameworks’
  5. If you have VMWare or Parallels installed you will have to deactivate the network interfaces they add. If you don’t do this you will probably be able to connect but have a very high packet loss rate. You may have similar issues with other products that interact with routing. To do this go to ‘System Preferences -> Network’ and change ‘Configure IPv4’ to ‘off’ for these extra interfaces. They will typically be named something like ‘Ethernet Adaptor (en2)’. Entries like these in the Network Connect log are indicative of this type of problem:
  6. sudo chmod 4711 /usr/local/juniper/nc/[version number]/ncproxyd
  7. If your kernel is running in 64 bit mode you will have to change it to 32 bit mode. This may no longer be true with newer versions of Network Connect but it is for version 6.2.0. You can change the kernel to 32 bit mode temporarily by shutting down then holding the 3 and 2 keys down while starting up.
Download

You should now be able to launch Network Connect from Applications. Since you did not use the applet installer you will have to enter your VPN URL. This does not include the path part of the URL. For example: https://vpn.mycompany.com.


The Juniper Networks Network Connect is a software package from Juniper Networks that interfaces with its Secure Access hardware and provides a Virtual Private Network (VPN) solution.

The Network Connect (NC) provides a clientless VPN user experience, serving as an additional remote access mechanism to corporate resources using an IVE appliance. This feature supports all Internet-access modes including dial-up, broadband, and LAN scenarios from the client machine and works through client-side proxies and firewalls that allow SSL traffic over port 443.

Juniper Network Connect For Mac Download

Network Connect takes all traffic to and from the client and transmits over the secure Network Connect tunnel. The only exception is for traffic initiated by other IVE-enabled features, such as Web browsing, file browsing, and telnet/
SSH. If you do not want to enable other IVE features for certain users, create a user role for which only the Network Connect option is enabled and make sure that users mapped to this role are not also mapped to other roles that enable other IVE features.

Juniper Network Connect 64

When Network Connect runs, the client effectively becomes a node on the remote
(corporate) LAN and becomes invisible on the user’s local LAN. The IVE appliance serves as the DNS gateway for the client and knows nothing about the user’s LAN. Users may define static routes on their PCs to continue to access the local LAN while simultaneously connecting to the remote LAN. For security consideration, because the PC traffic goes through the Network Connect tunnel to internal corporate resources, make sure that other hosts within that user’s LAN cannot connect to the PC running Network Connect. To download Juniper Network Connect you need to have a registered account with Juniper Networks and we have found a link for downloading Juniper Network Connect client which is given below.
